NUKON Ceramic Insulator-Yellow Upper Diamter: 25mm Down Diameter: 40mm Height: 35mm M11

Product detailed description

NUKON Ceramic Insulator-Yellow Upper Diamter: 25mm Down Diameter: 40mm Height: 35mm M11 — This ceramic head component electrically isolates the nozzle from the head body. It is part of the standoff measuring system and acts as a designed breakaway element that protects more expensive head parts in a collision. Application area: laser cutting heads.

Key features

• Electrical isolation of the nozzle for reliable capacitive height sensing
• Accurate location and centring of the nozzle against the head body
• Resistance to the high temperatures around the cutting zone
• Breakaway design that protects more expensive head components on impact

Technical information

• Type: Ceramic ring
• Order code: NRNUKNOM11

Application

The ring is fitted onto the cutting-head body and retains the nozzle. Keep the seating faces clean and free of slag, since contamination degrades height sensing. Replace a cracked or burned ring immediately, as it causes unstable standoff measurement and process faults.

Compatibility

Listed as compatible with NUKON equipment. Before purchase, compare the reference numbers and dimensions with the part installed in your machine.

Unless explicitly stated otherwise, this is an alternative part designed for compatibility with the corresponding equipment.
