SEI INFINITY V500 (2023)

Product detailed description

Laser Technology Specifications for V500

Laser Power: 540 W

Laser Wavelength: 10.6 µm (10.25–9.3 µm)

Pulse Frequency: 0–100 kHz

Cooling: Liquid Cooling (Closed Loop Cooler)

Scanning Head: IScan

Minimum Work Area: 500x500 mm

Spot Size: <1 mm

Maximum Work Area: 700x700 mm

Spot Size: <1 mm Z-Axis: 650 mm

Compressed Air Pressure: 1–6 bar Flow Rate: 0.2 l/min

Maximum Power Consumption 11 kW

20 A Cooler Included

Power Supply 3/N/PE AC 400V 50/60 Hz

Icaro Software Interface on Windows™ Platform Vector Image Import: .dxf; .plt (hpgl); .ai; .eps; .pdf Import of raster graphics: .bmp; .jpg; .tiff; .wmf; .pcd; .pnt; .pcx; etc.

Compliance with standards 2014/35/EU

Low Voltage Directive 2006/42/EC

Machinery Directive 2014/30/EU

Electromagnetic Compatibility Directive IEC EN 60825-1 Laser Safety
