Protective glass 62 x 9.5 AR/AR FS @ 1070nm 30KW

Product detailed description

Protective glass 62 x 9.5 AR/AR FS @ 1070nm 30KW — The cover glass is the last optical surface before the workpiece. It captures process contamination and is therefore the most frequently replaced optical part of the head. Application area: laser optics.

Key features

• Anti-reflective coating on both optical surfaces (AR/AR)
• Optimised for the 1070nm wavelength
• Protects the focusing optics from fume, dust and spatter
• High transmission at the laser working wavelength

Technical information

• Type: Protective window
• Dimensions: 62 x 9.5 mm
• Wavelength: 1070nm
• Power rating per designation: 30KW
• OEM / reference numbers: 5319581

Application

The window is inserted into the cover-glass cassette of the laser head. Handle it with clean gloves and only by the edge. A contaminated or burned window absorbs part of the beam power, heats up and can damage the optics behind it, so inspect it at the start of every shift and replace it at the first signs of contamination.

Compatibility

Determine compatibility using reference numbers 5319581. Compare them with the designation of the part installed in your machine and with the equipment documentation; contact us if anything is unclear and we will verify the version.

Unless explicitly stated otherwise, this is an alternative part designed for compatibility with the corresponding equipment.
